Microfluidic Chip, also called Lab-on-a-Chip, integrated biological, chemical, and medical analytical processes—including sample preparation, reaction, separation, and detection—onto a micron-scale chip, enabling fully automated analysis. It is recognized as a transformative innovation in life science, offering compact size consumption, low energy, rapid reaction speed, and high portability.

YIZUMI, with its micron-level precision injection molding technology, provides ultra-high-accuracy molding solutions for microfluidic chips. Using PMMA material, the chip’s core structure features a precision dot matrix with a diameter of 0.08 mm and a minimum spacing of 0.17 mm, fully demonstrating the equipment’s exceptional accuracy and stability.

>>Highlights 01

「Clamping unit」

• High Rigid Structure: Optimized platen, frame and injection unit design reduce platen surface deformation to below 0.03 mm.
• Separate Supports for Crosshead Guide Rod: The structure minimizes the impact of tail platen deformation on the crosshead, enhancing stability.
• Independent Reinforcement of Movable and Fixed Platens: The separate supports and optimized thermal conduction maintain platen parallelism and prevent thermal deformation.
• Precise Clamping Force Control: Encoder-based mold adjustment ensures accuracy within 3.5 kN.
• Ultra-High Guiding Accuracy: Liner guide rail design achieves 0.01mm straightness.

「Injection unit」

• Double-Ball-Screw Injection Unit Technology: This technology evenly distributes axial load, eliminating nozzle overtrumping force for stable injection.
• Smart Direct Control Technology: 0.125ms ultra-fast response ensures excellent motion precision.

「Cleaning design」

• The design features all-electric configuration with zero hydraulic oil pollution, compatible with various cleanroom levels and specialized for medical application.

>>Application Case?02

「Microfluidic Chip」

Cavity: 2?

Material: PMMA?

Size: 97.10×28.10×4.00mm?

Microstructure size: φ0.08mm?

Cycle: 15±1s?

Partner: Jester Mold, KUKA

Polymer injection molding is one of the key processes in microfluidic chip manufacturing. YIZUMI’s micro precision injection molding machine with its high-rigidity structural design, dedicated control system, and cleanroom compatibility, delivers micron-level molding precision to meet the medical industry’s stringent requirements for ultra-high accuracy and contamination-free production.

* All data are derived from YIZUMI's factory experiments.

Please refer to the customized equipment for product data.
